SWI100C-N Series
Specifications
- Power (W): 100
- Output Voltage (VDC): 5 ~ 20
- Input Voltage Range (VAC): 90 ~ 264
- Operating Temperature Range (ºC): -10 ~ +40
- Dimensions L x W x H (in): 2.48 x 2.42 x 1.18
- Dimensions L x W x H (mm): 63 x 61.5 x 30
- Blade Type: Fixed Blade
- DC Plug Type: USB Type C
- Safety Standards: 62368
- Safety Approvals: FCC, UL/cUL
- Protections: Over Current, Over Voltage, Short Circuit
- RoHS Compliant: Yes
Features
- USB power delivery (PD) 3.0 and PPS compliant
- Fixed or flip NA AC blade
- Over current protection (OCP)
- Short circuit protection (SCP)
- Over voltage protection (OVP)
- Customization available
- Black and White options available
