Through Hole Inductors
Providing robust and durable solutions for high-power and high-reliability applications, our inductors are purposed for environments with high mechanical stress, such as industrial equipment and automotive systems.
Product Resources
Blog Post
Selecting Surface Mount Inductors For DC to DC Converter Applications
Inductor Chokes/Coils
Get the most from your DC to DC Converters with our guide to selecting the right surface mount inductors.
Read Blog PostAttribute Filters
Inductance (µH)
Current (A)
DCR (Ohm)
Length (mm)
Width (mm)
Height (mm)
Shielding
Operating Temperature (ºC)
Packaging
11 Products
| Product | Inductance (µH) | Current (A) | DCR (Ohm) | Length (mm) | Width (mm) | Height (mm) | Shielding |
|---|---|---|---|---|---|---|---|
| 0.47 ~ 56 | 11.5 ~ 65 | 0.0004 ~ 0.012 | 21.8 ~ 36 | 18 ~ 35 | 12 ~ 22.5 | Yes | |
| 1.2 ~ 2200 | 0.1 ~ 1.95 | 0.058 ~ 17 | 5.5 | 5.5 | 8 | No | |
| 3.3 ~ 47000 | 0.03 ~ 3.4 | 0.013 ~ 160 | 7.5 ~ 10 | 7.5 ~ 10 | 9.5 ~ 11 | No | |
| 3.3 ~ 15000 | 0.12 ~ 5 | 0.012 ~ 24 | 10 ~ 12 | 10 ~ 12 | 13 | No | |
| 10 ~ 15000 | 0.18 ~ 5.1 | 0.017 ~ 10.5 | 12 ~ 14 | 12 ~ 14 | 16 ~ 21 | No | |
| 2.2 ~ 47000 | 0.03 ~ 5.6 | 0.021 ~ 99 | 8.7 | 8.7 | 12.5 | No | |
| 10 ~ 1000 | 2.4 ~ 14.3 | 0.006 ~ 0.216 | 28 | 14 | 28 | Yes | |
| 10 ~ 1000 | 2.4 ~ 20 | 0.005 ~ 0.3 | 32.5 | 16.5 | 32.5 | Yes | |
| 10 ~ 1000 | 1.6 ~ 9.9 | 0.012 ~ 0.43 | 22 | 11.4 | 22 | Yes | |
| 27 ~ 4700 | 0.1 ~ 1.28 | 0.058 ~ 10.5 | 6.6 | 6.6 | 16.5 | No | |
| 150 ~ 1800 | 0.3 ~ 3 | 0.078 ~ 1.55 | 23 ~ 43 | 22 ~ 48 | 13.1 ~ 32 | Yes |
Datasheet
