DMT-7 Series
DMT-7 Series

DMT-7 Series

Signal's DMT-7 Series transformers are 58VA single phase transformers in a chassis mount package. They are designed to convert 115 ~ 230V input to 5VDC, with ±12VDC, 5VDC, with ±15VDC output.
Features
  • Triple Output
  • Terminals Solder Lug / Quick Connect
  • UL 1446 E66312
  • CSA Certified to C22.2 #66.1
  • Easily Modified
Specifications
  • Power (VA): 58
  • Voltage - Primary (V): 115 ~ 230
  • Insulation Class: 130ºC, Class B
  • Dielectric Strength (Vrms): 2500
  • Mounting Type: Chassis Mount
  • Weight lbs (kg): 1.7 (0.77)
  • Dimensions L x W x H (in): 3.68 x 1.94 x 2.28
  • Dimensions L x W x H (mm): 93.5 x 49.3 x 57.9
  • Safety Standards: UL 5085
  • Safety Approvals: CSA, UL
  • RoHS Compliant: Yes
