BL-0060M Autotransformers
Autotransformer for Lighting Applications, 60 VA, 347 V Primary, 120 V Secondary
Stock Check
Country - USA
Features & Specifications
| Power (VA) | 60 |
| Voltage - Primary (V) | 347 |
| Voltage - Secondary (V) | 120 |
| Frequency (Hz) | 50/60 |
| Insulation Class | Class B, 130ºC |
| Mounting Type | Chassis Mount |
| Length in (mm) | 3.35 (85.09) |
| Width in (mm) | 1.68 (42.672) |
| Height in (mm) | 1.36 (34.544) |
| Weight lbs (kg) | 1.25 (0.57) |
| RoHS Compliant | Yes |
| Brand | Signal Transformer |
