SWI60C-E Series
4 Products
| Product | 3D Model | Power (W) | Input Voltage Range (VAC) | Output Voltage (VDC) | Output Current (A) | Operating Temperature Range (ºC) | Efficiency Standards | Blade Region | Blade Type |
|---|---|---|---|---|---|---|---|---|---|
SWI60C-V-EB-C-I40In stock
|
|
|
15, 27, 36, 45, 60 | 90 ~ 264 | 5, 9, 12, 15, 21 | 3 | 0 ~ +25 |
EU 2019/ |
Europe | Fixed Blade |
SWI60C-V-EB-I40In stock
|
|
|
15, 27, 36, 45, 60 | 90 ~ 264 | 5, 9, 12, 15, 21 | 3 | 0 ~ +25 |
EU 2019/ |
Europe | Fixed Blade |
SWI60C-V-EW-C-I40In stock
|
|
|
15, 27, 36, 45, 60 | 90 ~ 264 | 5, 9, 12, 15, 21 | 3 | 0 ~ +25 |
EU 2019/ |
Europe | Fixed Blade |
SWI60C-V-EW-I40In stock
|
|
|
15, 27, 36, 45, 60 | 90 ~ 264 | 5, 9, 12, 15, 21 | 3 | 0 ~ +25 |
EU 2019/ |
Europe | Fixed Blade |
Loading more products . . .
Technical Resources & Documents
Drawings & Datasheets
Safety Certificates
Tech Resources
Specifications
- Power (W): 15 ~ 60
- Output Voltage (VDC): 5 ~ 21
- Input Voltage Range (VAC): 90 ~ 264
- Operating Temperature Range (ºC): 0 ~ +25
- Blade Region: Europe
- Blade Type: Fixed Blade
- Safety Standards: 62368
- Safety Approvals: CE
- Protections: Over Current, Over Voltage, Short Circuit
- RoHS Compliant: Yes
Features
- No-load power consumption < 0.21 W
- USB Power Delivery (PD) 3.0
- Black and White options available
