SWH15-E Series
5 Products
| Model Series | 3D Model | Power (W) | Input Voltage Range (VAC) | Output Voltage (VDC) | Output Current (A) | Operating Temperature Range (ºC) | Efficiency Standards | Blade Region | Blade Type |
|---|---|---|---|---|---|---|---|---|---|
SWH15-5-EIn stock
|
|
|
10 | 90 ~ 264 | 5 | 2 | 0 ~ +40 | CoC Tier 2, Level VI | Europe | Fixed Blade |
SWH15-5B-EIn stock
|
|
|
15 | 90 ~ 264 | 5 | 3 | 0 ~ +40 | CoC Tier 2, Level VI | Europe | Fixed Blade |
SWH15-9-EIn stock
|
|
|
13.5 | 90 ~ 264 | 9 | 1.5 | 0 ~ +40 | CoC Tier 2, Level VI | Europe | Fixed Blade |
SWH15-12-EIn stock
|
|
|
12 | 90 ~ 264 | 12 | 1 | 0 ~ +40 | CoC Tier 2, Level VI | Europe | Fixed Blade |
SWH15-24-EIn stock
|
|
|
14.4 | 90 ~ 264 | 24 | 0.6 | 0 ~ +40 | CoC Tier 2, Level VI | Europe | Fixed Blade |
Loading more products . . .
Technical Resources & Documents
Drawings & Datasheets
Safety Certificates
Tech Resources
Specifications
- Power (W): 10 ~ 15
- Output Voltage (VDC): 5 ~ 24
- Input Voltage Range (VAC): 90 ~ 264
- Operating Temperature Range (ºC): 0 ~ +40
- Blade Region: Europe
- Blade Type: Fixed Blade
- Safety Standards: 60335, 61558
- Safety Approvals: CE
- Protections: Over Current, Over Voltage, Short Circuit
- RoHS Compliant: Yes
Features
- No-load power consumption < 0.1 W
- Ultra-compact case
- Black and White options available
