DM7809 SFP Transceivers
G.hn Wave-2 Ethernet bridge delivering up to 1.7Gbps over existing phone line or coax infrastructure
Stock Check
Country - USA
Features & Specifications
| Product Type | SFP G.hn/Ethernet Bridge |
| Transceiver Type | Specialty |
| Speed | G.hn Wave-2 (1.7Gbps) |
| Interface | SGMII |
| Max. Distance (m) | 100 |
| Power Consumption (W) | 1.9 |
| Connector Type | F-type (Coax), RJ-11 |
| Cable Type | Coaxial Cable, Twisted Pair |
| Latch Type | Bail Latch |
| Housing Type | Die Cast |
| Form Factor | SFP+ MSA |
| Operating Temperature Range (ºC) | -40 ~ +85 |
| Standards Compliance | INF-8074i, ITU-T G.9960, SFF-8432 |
| RoHS Compliant | Yes |
