F1C2-080808W-1R8M
SMD Inductors
Shielded SMD High Power Inductor, 1.8 uH, 18 A, 4 Ω DCR, Test Frequency 100 KHz
Stock Check
Country - USA
Features & Specifications
| Inductance (uH) | 1.8 |
| Current (A) | 18 |
| DCR (Ohm) | 4 |
| Current Saturation - Isat (A) | 22.5 |
| Operating Temperature (ºC) | -55 ~ +125 |
| Length (mm) | 8.8 |
| Test Frequency (KHz) | 100 |
| Width (mm) | 9.2 |
| Mounting Type | Surface Mount |
| Height (mm) | 8 |
| Packaging | Tape and Reel |
| RoHS Compliant | Yes |
| Shielding | Yes |
| Brand | Signal Transformer |
| AEC-Q200 Compliant | No |
