SDI100-D Series

The SDI100-D series is a 100W USB Power Delivery desktop with a 2 Prong (C8) AC inlet and USB-C DC connector. It's designed to meet Level VI efficiency standards and certified to 62368-1 safety standards as a continuation of Bel's initiative to provide customers with Global solutions for ITE & ICT/AV equipment.
Features
  • Level VI efficiency
  • USB power delivery (PD 3.0)
  • IEC320/C8 AC inlet
  • Over voltage, over current, and short circuit protection
  • Custom designs available
Specifications
  • Power (W): 100
  • Output Voltage (VDC): 5 ~ 20
  • Input Voltage Range (VAC): 90 ~ 264
  • Operating Temperature Range (ºC): 0 ~ +40
  • AC Inlet Type: 2 Prong (C8)
  • Input Cable Region: Europe, No Cable, North America
  • Safety Standards: 62368
  • Safety Approvals: CE, FCC, PSE, UL/cUL
  • Protections: Over Current, Over Voltage, Short Circuit
  • RoHS Compliant: Yes
