3D View
PEME2-S24-D24-S
DC-DC Converters
This product is Not Recommended for New Design (NRND) and availability is limited to remaining stock in distribution. Please contact tech support below with any questions.
Stock Check
Country - USA
Features & Specifications
| Power (W) | 2 |
| Input Voltage Range (VDC) | 21.6 ~ 26.4 |
| Output Voltage (VDC) | 24/-24 |
| Output Current (A) | 0.042/-0.042 |
| Number of Outputs | 2 |
| Dimensions L x W x H (mm) | 19.65 x 7.05 x 10.16 |
| Dimensions L x W x H (in) | 0.77 x 0.28 x 0.4 |
| Mounting Type | Through Hole Mount |
| Standard Footprint | SIP7 |
| Isolation (VDC) | 3000 |
| Isolated | Yes |
| Safety Standards | 62368 |
| Regulation | No |
| RoHS Compliant | Yes |
| Brand | CUI |
