MBC250 Series

The MBC1200 / MBE1200 Series of AC-DC power supplies provides up to 1200 W of regulated output power through wide input voltage range 85 - 305 VAC in a single output of 24 VDC or 48 VDC. The MBC1200 / MBE1200 Series is available in three compact 1U height compatible packages offering 12 and 5 VSB standby outputs and a full set of protection features. The MBC1200 / MBE1200 Series complies with the latest edition of the IEC/EN 60601-1 safety standards for medical equipment requiring 2x MoPP protection grade and displays the CE-Mark for the European Low Voltage Directive (LVD).

The MBC600 Series AC-DC/DC-DC power supply can operate using AC or DC input. It is a highly efficient frontend power supply. The PFC stage adopts an analog controller in continuous conduction mode to achieve high power factor and high efficiency. The DC/DC stage is fully DSP controlled and employs soft switching resonant techniques in conjunction with synchronous rectification for high efficiency and better thermal control. With a wide input operational voltage range and minimal linear derating of output power with temperature, the MBC600 Series maximizes power availability in demanding server, network, and other high availability applications. The supply is convection cooled or fan cooled and ideally suited for integration with a matching airflow path.
