F1F3-1054T-1R0M
SMD Inductors
High Current Shielded Power Inductor, 1 uH, 30 A, 0.0036 Ω DCR, Test Frequency 100 KHz
Stock Check
Features & Specifications
| Inductance (uH) | 1 |
| Current (A) | 30 |
| DCR (Ohm) | 0.0036 |
| Current Saturation - Isat (A) | 28 |
| Operating Temperature (ºC) | -55 ~ +155 |
| Length (mm) | 11 |
| Test Frequency (KHz) | 100 |
| Width (mm) | 10 |
| Mounting Type | Surface Mount |
| Height (mm) | 5.4 |
| Packaging | Tape and Reel |
| RoHS Compliant | Yes |
| Shielding | Yes |
| Brand | Signal Transformer |
| AEC-Q200 Compliant | Yes |
