SCIHP1367-100M
SCIHP1367-100M

DATASHEET
VIEW STOCK
Play

SCIHP1367-100M

Share

High Current Shielded SMD Power Inductor | Inductance 10uH | Test Frequency 200KHz | DC Resistance 0.0185Ω | Saturation Current 15.5A | Temperature Current 10A | Max Height 6.7mm

Email Form

DESCRIPTION

High Current Shielded SMD Power Inductor | Inductance 10uH | Test Frequency 200KHz | DC Resistance 0.0185Ω | Saturation Current 15.5A | Temperature Current 10A | Max Height 6.7mm

DOCUMENTS

SUPPORT

Email Form

REQUEST QUOTE





Saturation (A) 15.5
Temperature Rise (A) 10
Max Height (mm) 6.7
DCR (Ohm) 0.0185
Low EMI NO
Dimensions (mm) Max 12.9*13.8
Inductance (uH) 10
Test Frequency (KHz) 200
Shielding Shielded
Current (A) High
Low Profile NO
