SCIHP1350-6R8M

Share

High Current Shielded SMD Power Inductor | Inductance 6.8uH | Test Frequency 200KHz | DC Resistance 0.0198Ω | Saturation Current 18A | Temperature Current 10A | Max Height 5mm

Email Form

High Current Shielded SMD Power Inductor | Inductance 6.8uH | Test Frequency 200KHz | DC Resistance 0.0198Ω | Saturation Current 18A | Temperature Current 10A | Max Height 5mm

Email Form

Saturation (A) 18
Temperature Rise (A) 10
Max Height (mm) 5
DCR (Ohm) 0.0198
Low EMI NO
Dimensions (mm) Max 12.9*13.8
Inductance (uH) 6.8
Test Frequency 200KHZ
Shielding Shielded
Current (A) High
Low Profile NO
