High Current Shielded SMD Power Inductor | Inductance 4.7uH | Test Frequency 200KHz | DC Resistance 0.015Ω | Saturation Current 21A | Temperature Current 11A | Max Height 5mm

Email Form

DESCRIPTION

High Current Shielded SMD Power Inductor | Inductance 4.7uH | Test Frequency 200KHz | DC Resistance 0.015Ω | Saturation Current 21A | Temperature Current 11A | Max Height 5mm

SUPPORT

Email Form

REQUEST QUOTE

DOCUMENTS

Saturation (A) 21
Temperature Rise (A) 11
Max Height (mm) 5
DCR (Ohm) 0.015
Low EMI NO
Dimensions (mm) Max 12.9*13.8
Inductance (uH) 4.7
Test Frequency 200KHZ
Shielding Shielded
Current (A) High
Low Profile NO
