BM1601-9RAG

Railway Cassette DC-DC Converters

48 W DC-DC Rugged Melcher™ Cassette, 24 VDC, 2 A Output, 14 ~ 70 VDC Input Range, Rack Mount, Output Voltage Test Sockets Features: Output Voltage Control Input

Stock Check

Features & Specifications

Package 3U / 8HP cassette
Power (W) 48
Input Voltage Range (VDC) 14 ~ 70
Output Voltage (VDC) 24
Output Current (A) 2
Number of Outputs 1
Operating Temperature Range (ºC) -40 ~ +71
Mounting Type Rack Mount
Market ITE
Features Output Voltage Adjust (via Voltage)
Options Output voltage test sockets
Isolated Yes
Safety Standards 62368
Safety Approvals CB, CE, CSA, Nemko
RoHS Compliant Yes
Brand Melcher

Compatible Products with BM1601-9RAG
