DL-10-4 Single Phase Transformers
Rectifier Power Transformer | 40VA Power | 115V/230V Input | 50/60Hz Input
Stock Check
Country - USA
Features & Specifications
| Power (VA) | 40 |
| Voltage - Primary (V) | 115/230 |
| Voltage - Secondary Series | 10VCT |
| Voltage - Secondary Parallel | 5VCT |
| Frequency (Hz) | 50/60 |
| Insulation Class | Class B, 130ºC |
| Dielectric Strength (Vrms) | 1500 |
| Mounting Type | Chassis Mount |
| Weight lbs (kg) | 2.3 (1.04) |
| Dimensions L x W x H (in) | 3.56 x 2.37 x 3.06 |
| Dimensions L x W x H (mm) | 90.4 x 60.2 x 77.7 |
| Safety Approvals | CSA, UL |
| RoHS Compliant | Yes |
| Brand | Signal Transformer |
