Current Sense Transformers
Engineered for precise, non-invasive current detection in power supply circuits, safety systems, and control circuits, these surface mount components are ideal for applications such as feedback control and load drop, ensuring accurate and cost-effective performance.
Blog Post
How Isolation Transformers Increase Safety in Electronic Systems
Optimize safety with isolation transformers. Explore compliance, benefits in switching power supplies, and strategic selection insights.
Read Blog Post
Technical Paper
Controlling EMI in Power Transformers
Control EMI in Power Transformers with essential design solutions to prevent device failure and interference.
Read Technical PaperAttribute Filters
Current - Primary (A)
DCR - Primary (mOhm)
Inductance - Secondary (µH)
Turns Ratio - Primary:Secondary
EE Core size (mm)
Length in (mm)
Width in (mm)
Height in (mm)
| Product | 3D Model | Datasheet | Current - Primary (A) | DCR - Primary (mOhm) | Inductance - Secondary (µH) | Turns Ratio - Primary:Secondary | Frequency Range (KHz) | Dielectric Strength (Vrms) | EE Core size (mm) |
|---|---|---|---|---|---|---|---|---|---|
|
|
10 | 0.7 | 2000 | 100:1 | 50 ~ 1000 | 500 | 5 | |
|
|
|
10 | 0.7 | 3000 | 125:1 | 50 ~ 1000 | 500 | 5 | |
|
|
|
10 | 0.7 | 80 | 20:1 | 50 ~ 1000 | 500 | 5 | |
|
|
|
10 | 0.7 | 180 | 30:1 | 50 ~ 1000 | 500 | 5 | |
|
|
|
7 | 3 | 820 | 100:1 | 50 ~ 1000 | 500 | 4.4 | |
|
|
|
7 | 3 | 1280 | 125:1 | 50 ~ 1000 | 500 | 4.4 | |
|
|
|
7 | 3 | 1800 | 150:1 | 50 ~ 1000 | 500 | 4.4 | |
|
|
|
7 | 3 | 33 | 20:1 | 50 ~ 1000 | 500 | 4.4 | |
|
|
|
7 | 3 | 74 | 30:1 | 50 ~ 1000 | 500 | 4.4 | |
|
|
|
7 | 3 | 132 | 40:1 | 50 ~ 1000 | 500 | 4.4 | |
|
|
|
7 | 3 | 205 | 50:1 | 50 ~ 1000 | 500 | 4.4 | |
|
|
|
7 | 3 | 295 | 60:1 | 50 ~ 1000 | 500 | 4.4 | |
|
|
|
7 | 3 | 400 | 70:1 | 50 ~ 1000 | 500 | 4.4 | |
|
|
|
9 | 1.5 | 1330 | 1000:1 | 50 ~ 1000 | 500 | 4.6 | |
|
|
|
9 | 1.5 | 2993 | 150:1 | 50 ~ 1000 | 500 | 4.6 | |
|
|
|
9 | 1.5 | 53 | 20:1 | 50 ~ 1000 | 500 | 4.6 | |
|
|
|
9 | 1.5 | 333 | 50:1 | 50 ~ 1000 | 500 | 4.6 | |
|
|
|
9 | 1.5 | 652 | 70:1 | 50 ~ 1000 | 500 | 4.6 | |
|
|
|
10 | 0.7 | 320 | 40:1 | 50 ~ 1000 | 500 | 5 | |
|
|
|
10 | 0.7 | 500 | 50:1 | 50 ~ 1000 | 500 | 5 | |
|
|
|
10 | 0.7 | 730 | 60:1 | 50 ~ 1000 | 500 | 5 | |
|
|
|
10 | 0.7 | 980 | 70:1 | 50 ~ 1000 | 500 | 5 | |
|
|
|
15 | 3.9 | 5600 | 100:1 | 50 ~ 1000 | 500 | 8.3 | |
|
|
|
15 | 3.9 | 8700 | 125:1 | 50 ~ 1000 | 500 | 8.3 | |
|
|
|
15 | 3.9 | 12600 | 150:1 | 50 ~ 1000 | 500 | 8.3 |
