PEC1300 (DC-DC Intel Standard CRPS) Series
PEC1300 (DC-DC Intel Standard CRPS) Series

PEC1300 (DC-DC Intel Standard CRPS) Series

PEC1300-12-074xD is a 1300 Watt, CRPS DC to DC power supply module with a +12 V main DC output and a +12 V standby output. The power supply operates as a single supply, or N+1 parallel configuration. PEC1300-12-074xD utilizes full digital control architecture for greater efficiency, control and functionality. This power supply meets international safety standards and displays the CE-Mark for the European Low Voltage Directive (LVD).
Features
  • Intel Standard CRPS Form Factor
  • High Power Density
  • Supports N+1 Redundancy, Cold Redundancy, Internal ORing
  • Black Box Recorder, Bootloader
  • Clockwise and Counter-Clockwise Fan Rotation
  • Supports Power Management Bus Communication Protocol
Specifications
  • Power (W): 1300
  • Input Voltage Range (VDC): 72 ~ 72
  • Output Voltage (VDC): 12
  • Standby Output Voltage (VDC): 12
  • Operating Temperature Range (ºC): 0 ~ +50
  • Isolated: Yes
  • Safety Standards: 62368
  • Safety Approvals: BSMI, CB, CE, EAC, KCCEMC, KCCSafety, TUV, UL
  • RoHS Compliant: Yes
