P783-Q24-S9-S DC-DC Converters
This product is Not Recommended for New Design (NRND) and availability is limited to remaining stock in distribution. Please contact tech support below with any questions.
Stock Check
Country - USA
Features & Specifications
| Power (W) | 27 |
| Input Voltage Range (VDC) | 13 ~ 36 |
| Output Voltage (VDC) | 9 |
| Output Current (A) | 3 |
| Number of Outputs | 1 |
| Dimensions L x W x H (mm) | 32.15 x 9.05 x 18.95 |
| Dimensions L x W x H (in) | 1.266 x 0.356 x 0.746 |
| Mounting Type | Through Hole Mount |
| Standard Footprint | SIP12 |
| Features | Output Trimming (external resistance) |
| Options | Extended Temp Range |
| Isolation (VDC) | 0 |
| Isolated | No |
| Regulation | Yes |
| RoHS Compliant | Yes |
| Brand | CUI |
