DQD30-24-S3-T DC-DC Converters
19.8 W DC-DC Converter, 3.3 VDC, 6 A, 9 ~ 36 VDC Input Range, Chassis Mount
Stock Check
Country - USA
Features & Specifications
| Power (W) | 19.8 |
| Input Voltage Range (VDC) | 9 ~ 36 |
| Output Voltage (VDC) | 3.3 |
| Output Current (A) | 6 |
| Number of Outputs | 1 |
| Operating Temperature Range (ºC) | -40 ~ +105 |
| Dimensions L x W x H (mm) | 76 x 31.5 x 21.3 |
| Dimensions L x W x H (in) | 2.99 x 1.24 x 0.838 |
| Mounting Type | Chassis Mount |
| Standard Footprint | 1" x 1" |
| Market | ITE |
| Isolation (VDC) | 1500 |
| Isolated | Yes |
| Safety Standards | 62368 |
| Safety Approvals | CE, UKCA |
| Regulation | Yes |
| RoHS Compliant | Yes |
| Brand | CUI |
Compatible Products with DQD30-24-S3-T
Related Products
DQD30-24-S3
19.8 W DC-DC Converter, 3.3 VDC, 6 A, 9 ~ 36 VDC Input Range, Through Hole
View Product
Related Products
DQD30-24-S3-DIN
