3D View
AE40B-UW-S28 DC-DC Converters
This product is Not Recommended for New Design (NRND) and availability is limited to remaining stock in distribution. Please contact tech support below with any questions.
Stock Check
Country - USA
Features & Specifications
| Power (W) | 40 |
| Input Voltage Range (VDC) | 250 ~ 1500 |
| Output Voltage (VDC) | 28 |
| Output Current (A) | 1.43 |
| Number of Outputs | 1 |
| Dimensions L x W x H (mm) | 109 x 58.5 x 30 |
| Dimensions L x W x H (in) | 4.291 x 2.303 x 1.181 |
| Mounting Type | Through Hole Mount |
| Standard Footprint | DIP8 |
| Market | ITE |
| Isolation (VDC) | 5600 |
| Isolated | Yes |
| Safety Standards | 62109 |
| Safety Approvals | CE, UKCA |
| Regulation | Yes |
| RoHS Compliant | Yes |
| Brand | CUI |
