VPM-S500-03R AC-DC Converters
264 W AC-DC Power Supply, 3.3 VDC, 80 A Output, 90 ~ 264 VAC Input Range, Metal Case, Chassis Mount
Stock Check
Country - USA
Features & Specifications
| Power (W) | 264 |
| Input Voltage Range (VAC) | 90 ~ 264 |
| Number of Outputs | 1 |
| Output Voltage (VDC) | 3.3 |
| Output Current (A) | 80 |
| Operating Temperature Range (ºC) | 0 ~ +50 |
| Cooling Type | Fan |
| Dimensions L x W x H (mm) | 233.68 x 109.22 x 63.5 |
| Dimensions L x W x H (in) | 9.2 x 4.3 x 2.5 |
| Mounting Type | Chassis Mount |
| Package | Metal Case |
| Features | Current/Load Sharing (active), Output Trimming (external resistance), Power Factor Correction (Active), Power Good Signal, Remote On/Off, Remote Sense |
| Market | ITE |
| Safety Approvals | CE, UL/cUL |
| RoHS Compliant | Yes |
| Brand | CUI |
