VGS-150D Series
VGS-150D Series
VGS-150D Series
Left arrow Right arrow
Not Recommended for New Design (NRND)

VGS-150D Series

This product is Not Recommended for New Design (NRND) and availability is limited to remaining stock in distribution. Please contact tech support below with any questions.
Features
  • Active power factor correction (PFC)
  • Output trim
  • Remote on/off control
  • Meets EN 55032/CISPR32 Class B conducted/radiated emissions
  • Input over voltage category III design
  • Input surge resilience (300 Vac, 5 seconds)
Specifications
  • Power (W): 150 ~ 153.6
  • Input Voltage Range (VAC): 85 ~ 305
  • Output Voltage (VDC): 12 ~ 48
  • Operating Temperature Range (ºC): -20 ~ +50
  • Cooling Type: Convection
  • Safety Standards: 60335, 61558, 62368
  • Safety Approvals: CE, UL/cUL
  • RoHS Compliant: Yes
