VBM-70-48-H AC-DC Converters
70 W AC-DC Power Supply, 48 VDC, 1.46 A Output, 90 ~ 264 VAC Input Range, Enclosed, Through Hole
Stock Check
Country - USA
Features & Specifications
| Power (W) | 70 |
| Input Voltage Range (VAC) | 90 ~ 264 |
| Number of Outputs | 1 |
| Output Voltage (VDC) | 48 |
| Output Current (A) | 1.46 |
| Operating Temperature Range (ºC) | -40 ~ +85 |
| Cooling Type | Baseplate, Convection, Heatsink |
| Dimensions L x W x H (mm) | 61 x 57.9 x 17 |
| Dimensions L x W x H (in) | 2.4 x 2.24 x 0.67 |
| Mounting Type | Through Hole Mount |
| Package | Enclosed |
| Market | ITE |
| Safety Standards | 62368 |
| Safety Approvals | CE, UKCA, UL/cUL |
| RoHS Compliant | Yes |
| Brand | CUI |
