S PFC Series
Specifications
- Power (W): 82 ~ 101
- Input Voltage Range (VAC): 85 ~ 264
- Output Voltage (VDC): 5.1 ~ 30
- Operating Temperature Range (ºC): -40 ~ +71
- Cooling Type: Convection
- Safety Standards: 62368
- Safety Approvals: CB, CE, CSA, Nemko
- RoHS Compliant: Yes
Features
- RoHS lead-free-solder and lead-solder-exempted products are available.
- Class I equipment
- Input over- and undervoltage lockout
- Adjustable output voltage with remote on/off
- Rectangular current limiting characteristic
