PSK-20F-3 AC-DC Converters
This product is Not Recommended for New Design (NRND) and availability is limited to remaining stock in distribution. Please contact tech support below with any questions.
Stock Check
Country - USA
Features & Specifications
| Power (W) | 20 |
| Input Voltage Range (VAC) | 85 ~ 305 |
| Number of Outputs | 1 |
| Output Voltage (VDC) | 3.3 |
| Output Current (A) | 4 |
| Operating Temperature Range (ºC) | -40 ~ +85 |
| Cooling Type | Convection |
| Dimensions L x W x H (mm) | 52.4 x 27.2 x 24 |
| Dimensions L x W x H (in) | 2.063 x 1.07 x 0.945 |
| Mounting Type | Through Hole Mount |
| Package | Plastic Case |
| Market | ITE |
| Safety Standards | 62368 |
| Safety Approvals | CE, UKCA, UL/cUL |
| RoHS Compliant | Yes |
| Brand | CUI |
