LFMWLP350-1006-EX AC-DC Converters
Medical AC-DC Power Supply | Power 350 W | Output 58 VDC, 6.04 A | Input 90 ~ 264 VAC | Fan Cooling | Open Frame | Screw Terminal | 7 years Warranty | RoHS Compliant
Stock Check
Country - USA
Features & Specifications
| Power (W) | 350 |
| Input Voltage Range (VAC) | 90 ~ 264 |
| Number of Outputs | 1 |
| Output Voltage (VDC) | 58 |
| Output Current (A) | 6.04 |
| Operating Temperature Range (ºC) | -40 ~ +70 |
| Cooling Type | Fan |
| Dimensions L x W x H (mm) | 127 x 76.2 x 25.4 |
| Dimensions L x W x H (in) | 5 x 3 x 1 |
| Mounting Type | Chassis Mount |
| Package | Open Frame |
| Connector | Screw Terminal |
| Features | 7 year Warranty |
| Market | Medical |
| Safety Standards | 60601 |
| Safety Approvals | CB, CE, Nemko, UL |
| RoHS Compliant | Yes |
| Brand | Bel |
Compatible Products with LFMWLP350-1006-EX
Accessories
LFWLP350-CK
Cover Kit for use with WLP350, MWLP350 Series open frame power supply. Non-corrosive, easy assembly, low weight, fully safe, access for AC and DC connectors.
