0ZRB Series
0ZRB Series

DATASHEET


0ZRB Series

Share

0ZRB Series is AEC-Q Compliant radial lead PTC resettable fuse with very high hold currents and low DCR resistance. Maximum voltage 30V DC, operating (hold current) range 900mA - 9A, max current 40A, operating temperature -40ºC to 85ºC.

Specifications

  • AEC-Q Compliant
  • Operating Range: 900mA - 9A
  • Maximum Voltage: 30 V DC
  • Max Current: 40A
  • Operating Temperature: -40ºC to +85ºC

Features

  • High Hold Currents
  • Low DCR Resistance

Email Form

SPECIFICATIONS

0ZRB Series is AEC-Q Compliant radial lead PTC resettable fuse with very high hold currents and low DCR resistance. Maximum voltage 30V DC, operating (hold current) range 900mA - 9A, max current 40A, operating temperature -40ºC to 85ºC.

Specifications

  • AEC-Q Compliant
  • Operating Range: 900mA - 9A
  • Maximum Voltage: 30 V DC
  • Max Current: 40A
  • Operating Temperature: -40ºC to +85ºC

Features

  • High Hold Currents
  • Low DCR Resistance
