0ZRA Series
0ZRA Series

DATASHEET


0ZRA Series

Share

0ZRA Series is AEC-Q Compliant radial lead PTC resettable fuse with very high hold currents and low DCR resistance. Maximum voltage 16V DC, operating (hold current) range 3A - 14A, max current 100A, operating temperature -40ºC to 85ºC.

Specifications

  • AEC-Q Compliant
  • Operating Range: 3A - 14A
  • Maximum Voltage: 16 V DC
  • Max Current: 100A
  • Operating Temperature: -40ºC to +85ºC

Features

  • Very High Hold Currents
  • Low DCR Resistance

Email Form

SPECIFICATIONS

0ZRA Series is AEC-Q Compliant radial lead PTC resettable fuse with very high hold currents and low DCR resistance. Maximum voltage 16V DC, operating (hold current) range 3A - 14A, max current 100A, operating temperature -40ºC to 85ºC.

Specifications

  • AEC-Q Compliant
  • Operating Range: 3A - 14A
  • Maximum Voltage: 16 V DC
  • Max Current: 100A
  • Operating Temperature: -40ºC to +85ºC

Features

  • Very High Hold Currents
  • Low DCR Resistance
