P7824-500R DC-DC Converters
This product is Not Recommended for New Design (NRND) and availability is limited to remaining stock in distribution. Please contact tech support below with any questions.
Stock Check
Country - USA
Features & Specifications
| Power (W) | 7.2 |
| Input Voltage Range (VDC) | 36 ~ 90 |
| Output Voltage (VDC) | 24 |
| Output Current (A) | 0.3 |
| Number of Outputs | 1 |
| Dimensions L x W x H (mm) | 19 x 11.5 x 9 |
| Dimensions L x W x H (in) | 0.75 x 0.45 x 0.35 |
| Mounting Type | Through Hole Mount |
| Standard Footprint | SIP3 |
| Options | Extended Temp Range |
| Isolation (VDC) | 0 |
| Isolated | No |
| Safety Standards | 62368 |
| Safety Approvals | CE, UKCA |
| Regulation | Yes |
| RoHS Compliant | Yes |
| Brand | CUI |
